Concrete bucket with side discharge and geared opening
BO-HRectangular bucket for concrete with wheel opening
We enthusiastically introduce the BO-H model of our concrete bucket, designed to deliver excellent performance and maximum versatility on your construction site. Characterized by a rectangular shape, this bucket features a long and narrow side discharge, ideal for precise placement of concrete into formworks or environments requiring precise pours.
Application sectors:
Construction
Finish Type:
Painted
Versions available
| Code | Image | Active variant image | Capacity (kg) | Capacity (L) | Weight (kg) | Adjustment (mm) | Internal Pipe Ø (mm) | Max opening (mm) | Dimension A (mm) | Dimension B (mm) | Dimension C (mm) | Dimension D (mm) | Dimension E (mm) | Dimension F (mm) | Dimension G (mm) | Dimension I (mm) | Dimension H (mm) | Dimension L (mm) | Dimension M (mm) | Length (mm) | Width (mm) | Height (mm) | Motor | Frequency (Hz) | Speed (giri/min) | Blade Ø (mm) | H Max Cut (mm) | Engine power (cv) | Disc diameter (mm) | Power supply (V) | Useful height (mm) | Total height (mm) | Base diameter (mm) | Diameter (mm) | No. of 200L drums | No. of 1000L tanks | Max load (daN) | Loading opening (mm) | Max liquid temperature (°C) | Max. pipe length (mm) | Max. length (mm) | Cutting width (mm) | H Cut (mm) | Minimal cut | H Wheels (mm) | Technical data notes | Image Name | No. of legs | No. of people | Pubblica nel sito web | Products | Custom price lists | Request Info |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BO-50H | 1200 | 500 | 180 | 1237 | 1284 | 1118 | 722 | 137 | 1 | ||||||||||||||||||||||||||||||||||||||||||||
| BO-75H | 1800 | 750 | 220 | 1463 | 1533 | 1125 | 722 | 137 | 1 | ||||||||||||||||||||||||||||||||||||||||||||
| BO-99H | 2400 | 1000 | 250 | 1633 | 1675 | 1125 | 722 | 137 | 1 | ||||||||||||||||||||||||||||||||||||||||||||
| BO-150H | 3600 | 1500 | 325 | 1886 | 1853 | 1270 | 725 | 137 | 1 |
| Cod. | Code | Image | Active variant image | Capacity (kg) | Capacity (L) | Weight (kg) | Adjustment (mm) | Internal Pipe Ø (mm) | Max opening (mm) | Dimension A (mm) | Dimension B (mm) | Dimension C (mm) | Dimension D (mm) | Dimension E (mm) | Dimension F (mm) | Dimension G (mm) | Dimension I (mm) | Dimension H (mm) | Dimension L (mm) | Dimension M (mm) | Length (mm) | Width (mm) | Height (mm) | Motor | Frequency (Hz) | Speed (giri/min) | Blade Ø (mm) | H Max Cut (mm) | Engine power (cv) | Disc diameter (mm) | Power supply (V) | Useful height (mm) | Total height (mm) | Base diameter (mm) | Diameter (mm) | No. of 200L drums | No. of 1000L tanks | Max load (daN) | Loading opening (mm) | Max liquid temperature (°C) | Max. pipe length (mm) | Max. length (mm) | Cutting width (mm) | H Cut (mm) | Minimal cut | H Wheels (mm) | Technical data notes | Image Name | No. of legs | No. of people | Pubblica nel sito web | Products | Custom price lists | Request Info |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BO-50H | BO-50H | 1200 | 500 | 180 | 1237 | 1284 | 1118 | 722 | 137 | 1 | ||||||||||||||||||||||||||||||||||||||||||||
| BO-75H | BO-75H | 1800 | 750 | 220 | 1463 | 1533 | 1125 | 722 | 137 | 1 | ||||||||||||||||||||||||||||||||||||||||||||
| BO-99H | BO-99H | 2400 | 1000 | 250 | 1633 | 1675 | 1125 | 722 | 137 | 1 | ||||||||||||||||||||||||||||||||||||||||||||
| BO-150H | BO-150H | 3600 | 1500 | 325 | 1886 | 1853 | 1270 | 725 | 137 | 1 |
